7.0% Break Elongation Brass-plated Mild Steel Wire Reinforcement for Oil Drilling 0.89mm ISO9001 manufacturer from China Zhangjiagang City Shengda Steel Wire Rope Co.

7.0% Break Elongation Brass-plated Mild Steel Wire Reinforcement for Oil Drilling 0.89mm

Place of Origin:

Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ISO9001

7.0% Break Elongation Brass-plated Mild Steel Wi

7.0% Break Elongation Brass-plated Mild Steel Wire Reinforcement for Oil Drilling 0.89mm

Specifications:

Description	BEAD WIRE		Reference		GB/T14450- 2008		Diameter		Φ0.89mm
Item			Standard				Result
Diameter(mm)			0.89±0.02				0.87-0.91
Break force (N)			≥1950				1990-2160
Yield rate (%)			93.0-96.0				93.3-94.9
Elongation at break(%)			≥5.0				7.0-8.5
Torsion(360°/200d)			≥50				59-75
Residual torsion (° /9m)			360				90-120
Bronze coated(g/kg)			0.35-0.65				0.40-0.51
Sn (%)			0.5-3.0				0.7-1.5
Straightness (mm/3m)			≤500				180-460
Adhesion (N/50mm)			≥1200				1242
Surface Quality			Coating Smooth and uniform				conform
Assay of chemical contents
C		Mn		Si		P		S
0.70-0.72		0.50-0.60		0.17-0.26		0.006-0.016		0.005-0.018

Description:

Hose wire is also called steel wire for hose reinforcement, brass-plated steel wire, rubber tube wire, or brass rubber tube wire. It is used as the reinforcement layer of the rubber hose. These high-pressure rubber hoses could sustain high pressure and high impact, and they can be used for machinery, aviation, ocean, oil drilling and some other special occasions. The hose reinforcement steel wire is carried out in line with GB/T 11182-2006 Standard, We mainly produce hose reinforcement steel wire with the diameter of 0.20mm to 0.8mm. Other specifications according to customers' requirements are also available.The surface of steel wire for hose reinforcement is plated a layer of uniform copper zinc alloy. The ratio of copper to zinc is 68±4%:32±4%. The tensile strength is mainly classified as three grades: 2150-2450, 2450-2750, 2750-3050, 3050-3350N/mm2, the torsion value is more than 50 times, and knotting strength ratio is more than 58%. The weight of brass coating is heavier than 3.0g/kg. The steel wire has good line shape, the diameter of cast is no less than 120mm, and the helix is no more than 50mm.
